Steel Structure Prefabricated Warehouse Building Industrial Flexible Layout

Brand Name : xgz

Model Number : cherry0116001

Certification : CE SGS ISO

Place of Origin : CHINA

MOQ : 50 SQM

Price : USD 39.9-69.9 SQM

Payment Terms : T/T

Supply Ability : 5000 ton per month

Delivery Time : 45 working days

Packaging Details : suitable for sea shipping

Steel Structure : Portal Frame, Truss Structure

Surface Treatment of Steel Structure : Painted or Galvanized

Roof and Wall Sheet : Single Sheet or Insulated Sandwich Panel

Paint Type : Acrylic Acid, Epoxy, Alkyd, Epoxy Resin, Epoxy Mic

Sandwich Panel : EPS, Fiberglass, Rockwool, PU

Connection : Welded or Bolted Connection

Software : CAD, Tekla, Sketchup, Pkpm, Bim, etc

Contact Now

Product Description

Prefabricated Construction Building Material Industrial Factory Hangar Shed Steel Structure Prefabricated Warehouse

Features of Steel Workshop
1. Flexible layout
2.Good ductility, strong plasticity and deformability, high seismic resistant and wind resistant
3.Quick build and long service time
4. Light weight,high quality but low cost
5.Environmental, Material can be 100% recycled or degraded

Products Details
Product Name : Prefabricated Steel Structure Workshop for Factory
Structure System: Light steel structure
Area: 23772m2

1. Main workshop: 198.1*120m*13.2 (Length* Width* Eave Height), Ridge Height: 18.6m

2. Primary Steel Structure: Lattic steel column without anchor bolts+ H section steel beam+Crane Beam

3. Secondary Framing: C Purlin, Tie Bar, Roof and Wall Support, Bracing are formed as secondary frameing.

4. Roof Cladding: Single Steel Sheet+Glasswool Blanket with Aluminium-foil+Wire Mesh

5. Wall Cladding: Single Corrugated Steel Sheet+Glass Curtain

6. Lighting System: Skylight Panel

7. Roof Vent: 36pcs Ventilator+8pcs E-clerestory

8. Window: Aluminium alloy Window+ Tinted Glass Curtain

9. Door: Sliding Door

ALL THE DESIGN CAN BE CUSTOMIZED AS REQUIRED.

Main Material Can Be Choosed

1.Thickness of steel sheet	0.35-0.60mm
2.Material of sandwich panel classes	fiberglass wool, rock wool, EPS, PU
3.Thickness of sandwich panel classes	50mm,75mm,100mm(ordinary thickness)
4.Material of purlin	galvanized C/Z section steel
5.Door	sliding door,lifting door,electric rolling door,aluminum alloy door, steel door
6.Window	plastic steel window/aluminum alloy window

The load bearing parts for steel structure workshop are mainly steel structures, including steel columns, steel beams, steel structural basements, bracing systems for wall and roof. Steel workshops are divided into Light Steel Workshops and Heavy Steel Workshops. The Main Structure are usually made of Q345 Steel while the Purlins and Bracing System are made of Q235 Steel. They are the most common steel materials used for steel structure in China.
Advantages of Steel Structural Workshop:
1).Large span for great strength with light deadweight;
2).Short finishing time and low cost;
3).Fire proof and rust proof;
4).Convenient to assemble or disassemble.

Main parts and materails of steel structure workshop :

No.	Ltem	Spec.	Grade	Unit.
1	Main Steel System
	Main Steel Frame		Q345B	T
	Manufacture charge			T
2	Secondary part Steel system
	Roof purlin	C1807020*2.5	Q235B	T
	Wall purlin	C1807020*2.5	Q235B	T
	Brace between column, Horizontal support	Angle steel Φ20	Q235B	T
	Knee bracing	Steel Angle L50*4	Q235B	T
	Tie bar	Square tubeΦ114*2.5	Q235B	T
	Support bar	round tubeΦ32*2.5	Q235B	T
	Brace between purlin	round barΦ12	Q235B	T
3	roof System
	Roof panel	0.5mmthickness corrugated steel sheet V820		m
	Skylight panel	1.2mm thick		m
	Standard Parts	Self-tapping screw,sealing tape,sealant		m
	Non-standard Parts	Colored profile parts for ridge,roof		m
	Gutter			m
	Downpipes			m
4	Wall System
	wall panel	0.45mm thick corrugated steel sheet V820		m
	Standard Parts	Self-tapping screw,sealing tape,sealant		m
	Non-standard Parts	Colored profile parts for edge cover,flashing		m
	Door	Colored steel panel door		m2
	Window	Plstic Steel Window		m2
	Awning			m2
5	Fastners
	Foundation bolts	M24x70		SET
	High strength bolts	M20		SET
	Common bolts	M12		SET
